Description
– Unique design concepts for best technical and most musical performance
– All tube amplification with integrated input- and output-transformers
– Sub miniature vacuum tube, originally produced for US missile technology
– All circuits built-into a dedicated case milled out of one solid block of aluminium
– Advanced airflow and anti-vibration control technology
Product Specifications
Inputs
MC, sensitivity 1mV on RCA
Outputs
Line level 1.55 V on XLR
Overall Gain
64dB nominal / 70dB max.
Signal to Noise
>70dB
THD & N
<-40dB @ 1kHz and nominal level
Mode
Stereo / Mono
Curve
RIAA / DIN 78 selectable
Mains
230 VAC, 115 VAC or 100 VAC
Power Consumption
25 Watts
Operation temperature
18…25°C / 65…77°F
Operating environment
for indoor use only
Dimensions
480x315x60 mm / 19×12.5×2.3 inches
Weight
12kg / 26.5 lbs
